EXPLORE SKOOLIE 50A WIRING KIT

This 50A Skoolie Electrical System Wiring Kit is based around a Victron Multiplus-II 12/3000 120-50 2x120V Inverter/Charger. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.

Click the arrow next to each kit name for specifics on what is included in the kit.

*Batteries are NOT included in this kit, but after your purchase, you will receive a discount code for Battle Born Batteries. Options for batteries are listed in the product description below.

START WITH YOUR BASE KIT #1 BELOW:

SKU: bundle-explore-skoolie-50a Categories: ,

Description

EXPLORE SKOOLIE 50A WIRING KIT

This 50A skoolie electrical system wiring kit features a Victron Multiplus-II 12/3000 120-50 2x120V Inverter/Charger for a skoolie with 50A shore power, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components (EXCLUDING BATTERIES), wiring, fusing, and connectors for:

  • Victron MultiPlus-II 12/3000 120-50 2x120V Inverter/Charger
  • Wiring Kit for 6 Batteries
  • Victron Lynx Distributor
  • Victron BMV-712 Monitoring
  • Victron VE.Bus Smart Dongle
  • Progressive Dynamics 120V AC Distribution Panel
  • Progressive Dynamics 12V DC Fuse Panel
  • 50A Shore Power Inlet (Black)
  • Victron SmartSolar MPPT 150|85 Solar Charge Controller
  • Six (6) Rich Solar 200W 12V Solar Panels
  • Victron Orion TR-Smart 12-12|30 Isolated DC-DC Charger

BATTERY OPTIONS FOR EXPLORE 50A SKOOLIE WIRING KIT

The following battery options are suitable for this system. The required minimum quantity is listed below:

COMPONENT QUANTITY LINK TO BUY
Suitable Battery Options (minimum 400Ah required):
Battle Born 100Ah 12V LiFePO4 Deep Cycle Battery 4+ CLICK TO BUY
Battle Born 100Ah GC2 12V LiFePO4 Deep Cycle Battery 4+ CLICK TO BUY
Battle Born 270Ah 12V LiFePO4 Deep Cycle GC3 Battery 2+ CLICK TO BUY
Battle Born 270Ah 12V LiFePO4 Deep Cycle Heated GC3 Battery 2+ CLICK TO BUY

SKOOLIE ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:

Installation tutorial shown in the video below shows the complete installation of this system. Some products may vary.

https://youtu.be/01F4QDVJUq0
