EXPLORE 24V 50A TOW BEHIND CAMPER WIRING KIT

Description

EXPLORE 24V 50A TOW BEHIND CAMPER WIRING KIT

This customizable tow behind camper electrical system kit features a Victron MultiPlus-II 24/3000 70-50 2x120V Inverter/Charger and includes the batteries, components, wiring kits, fusing, and connectors needed to build the system shown in the diagram.

The default selections include the components, wiring, fusing, and connectors for:

• Victron MultiPlus-II 24/3000 70-50 2x120V Inverter/Charger
• Two Epoch 24V 230Ah V2 Elite Series LiFePO4 Batteries
• 50A OEM RV Inverter/Charger Retrofit Splice Box
• Victron Lynx Distributor
• Victron BMV-712 Battery Monitor and VE.Bus Smart Dongle
• 1,000W Roof-Mounted Solar Array with Victron SmartSolar MPPT 150|35
• 400W Ground Deploy Solar Array with Victron SmartSolar MPPT 75|15
• Victron Orion XS 1400 DC-DC Charger for Alternator Charging
• This kit is based around this EXPLORE 24V 50A TOW BEHIND CAMPER WIRING DIAGRAM

The default selections are shown in the bundle builder but can be customized based on the needs of your system. Wiring kits can be selected as Un-Crimped (DIY) or upgraded to Pre-Crimped (PRO) wiring, professionally cut, crimped, heat-shrunk, and labeled by our in-house team.

Not sure what you need? Reach out to our support team at https://shop.explorist.life/support, and we’ll get you pointed in the right direction.

Want us to install it for you? Learn more at https://shop.explorist.life/installations/.

---

EXPLORE 24V 50A TOW BEHIND CAMPER WIRING KIT FULL TUTORIAL:

Installation tutorial shown in the video below shows the same concepts in a different system. Some products may vary. See our Installation and Product Tutorials for additional installation instructions.
