EXPLORE LITE VAN WIRING KIT
This is the DIY camper van electrical system wiring kit featuring a Victron Multiplus 2000VA Inverter/Charger, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components (EXCLUDING BATTERIES), wiring, fusing, and connectors for:
- Victron MultiPlus 12/2000 80-50 120V Inverter/Charger
- Wiring Kit for 4 Batteries
- Victron Lynx Distributor
- Victron BMV-712 Monitoring
- Victron VE.Bus Smart Dongle
- Progressive Dynamics 120V AC Distribution Panel
- Progressive Dynamics 12V DC Fuse Panel
- 30A Shore Power Inlet (Black)
- Victron SmartSolar MPPT 100|30 Solar Charge Controller
- Two (2) Rich Solar 200W 12V Solar Panels
- Victron Orion XS 12-12|50 Non-Isolated DC-DC Charger
BATTERY OPTIONS FOR EXPLORE LITE VAN WIRING KIT
The following battery options are suitable for this system. The required minimum quantity is listed below:
COMPONENT | QUANTITY | LINK TO BUY |
Suitable Battery Options (minimum 200Ah required): | ||
Battle Born 100Ah 12V LiFePO4 Deep Cycle Battery | 2+ | CLICK TO BUY |
Battle Born 100Ah GC2 12V LiFePO4 Deep Cycle Battery | 2+ | CLICK TO BUY |
Battle Born 270Ah 12V LiFePO4 Deep Cycle GC3 Battery | 1+ | CLICK TO BUY |
Battle Born 270Ah 12V LiFePO4 Deep Cycle Heated GC3 Battery | 1+ | CLICK TO BUY |
CAMPER VAN ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:
Installation tutorial shown in the video below shows the same concepts in a different system. Some products may vary.
