EXPLORE LITE 12V 30A SKOOLIE WIRING KIT

This Skoolie Electrical System Wiring Kit is based around a Victron 2000VA Inverter. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.

Click the arrow next to each kit name for specifics on what is included in the kit.

START WITH YOUR BASE KIT #1 BELOW:

SKU: bundle-explorelight-skoolie Categories: ,

Description

EXPLORE LITE 12V 30A SKOOLIE WIRING KIT

This customizable skoolie electrical system kit features a Victron MultiPlus 12/2000 80-50 120V Inverter/Charger and includes the batteries, components, wiring kits, fusing, and connectors needed to build the system shown in the diagram.

The default selections include the components, wiring, fusing, and connectors for:

• Victron MultiPlus 12/2000 80-50 120V Inverter/Charger
• 2 SOK 12V 314Ah LiFePO4 Batteries
• Victron Lynx Distributor
• Victron Cerbo GX MK2, GX Touch 70, and SmartShunt 500A Monitoring
• 120V AC Distribution Panel
• 12V DC Fuse Panel
• 30A Shore Power Inlet, Cord, and Adapter
• 500W Roof-Mounted Solar Array with 2 Rich Solar 250W Solar Panels and a Victron SmartSolar MPPT 100|50
• 200W Ground Deploy Solar Array with a Rich Solar 200W Portable Solar Panel Briefcase and Victron SmartSolar MPPT 75|15
• Victron Orion XS 12|12-70 Non-Isolated Alternator Charging
• 12V and 120V Branch Circuits
• EXPLORE LITE 12V 30A Van/Expedition Truck/Skoolie Wiring Diagram

The default selections are shown in the bundle builder but can be customized based on the needs of your system. Wiring kits can be selected as Un-Crimped (DIY) or upgraded to Pre-Crimped (PRO) wiring, professionally cut, crimped, heat-shrunk, and labeled by our in-house team.

Not sure what you need? Reach out to our support team at https://shop.explorist.life/support, and we’ll get you pointed in the right direction.

Want us to install it for you? Learn more at https://shop.explorist.life/installations/.

EXPLORE LITE 12V 30A SKOOLIE WIRING KIT FULL TUTORIAL:

Installation tutorial shown in the video below shows the same concepts in a different system. Some products may vary.
