EXPLORE XX 50A TOW BEHIND CAMPER DUAL INVERTER WIRING KIT

This 50A Tow Behind Camper 24V Electrical System Wiring Kit is based around dual Victron 24V 3000VA Inverters. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.

Click the arrow next to each kit name for specifics on what is included in the kit.

*Batteries are NOT included in this kit, but after your purchase, you will receive a discount code for Battle Born Batteries. Options for batteries are listed in the product description below.

START WITH YOUR BASE KIT #1 BELOW:

SKU: bundle-exploremore-50atowbehindcamper-24v-1 Categories: ,

Description

EXPLORE XX 50A TOW BEHIND CAMPER DUAL INVERTER WIRING KIT

This is the DIY 50A Tow Behind Camper electrical system wiring upgrade kit featuring two Victron Multiplus-II 24V 3000VA 2×120 Inverter/Chargers, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components (EXCLUDING BATTERIES), wiring, fusing, and connectors for:

  • Two (2) Victron MultiPlus-II 24/3000 70-50 2x120V Inverter/Chargers
  • 50A OEM RV Inverter/Charger Retrofit Splice Box
  • Dual Inverter/Charger Splitter Box
  • Wiring Kit for 4 12V Batteries in a 24V Battery Bank
  • Two (2) Victron Lynx Distributors
  • Victron Cerbo GX Monitoring
  • Victron SmartSolar MPPT 150|60 Solar Charge Controller
  • Eight (8) Rich Solar 200W Solar Panels
  • Dual Victron Orion TR-Smart 12-24|15 Isolated DC-DC Chargers

BATTERY OPTIONS FOR EXPLORE XX 50A TOW BEHIND CAMPER DUAL INVERTER WIRING KIT

The following battery options are suitable for this system. The required minimum quantity is listed below:

COMPONENTQUANTITYLINK TO BUY
Suitable Battery Options (minimum 400Ah required):
Battle Born 100Ah 12V LiFePO4 Deep Cycle Battery8+CLICK TO BUY
Battle Born 100Ah GC2 12V LiFePO4 Deep Cycle Battery8+CLICK TO BUY
Battle Born 270Ah 12V LiFePO4 Deep Cycle GC3 Battery4+CLICK TO BUY
Battle Born 270Ah 12V LiFePO4 Deep Cycle Heated GC3 Battery4+CLICK TO BUY

50A TOW BEHIND CAMPER DUAL INVERTER ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:

Installation tutorial shown in the video below shows the same concepts in a different system. Some products may vary. See our Installation and Product Tutorials for additional installation instructions.



Additional information

Battery Bank Voltage

24V

Application

Tow-Behind Camper

Shore Power Amperage

50A
