EXPLORE LITE EXPEDITION TRUCK WIRING KIT

This Expedition Truck Electrical System Wiring Kit is based around a Victron 2000VA Inverter. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.

Click the arrow next to each kit name for specifics on what is included in the kit.

START WITH YOUR BASE KIT #1 BELOW:

SKU: bundle-explorelight-expeditiontruck Categories: ,

Description

EXPLORE LITE EXPEDITION TRUCK WIRING KIT

This is the DIY expedition truck electrical system wiring kit featuring a Victron Multiplus 2000VA Inverter/Charger, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components (EXCLUDING BATTERIES), wiring, fusing, and connectors for:

  • Victron MultiPlus 12/2000 80-50 120V Inverter/Charger
  • Wiring Kit for 4 Batteries
  • Victron Lynx Distributor
  • Victron BMV-712 Monitoring
  • Victron VE.Bus Smart Dongle
  • Progressive Dynamics 120V AC Distribution Panel
  • Progressive Dynamics 12V DC Fuse Panel
  • 30A Shore Power Inlet (Black)
  • Victron SmartSolar MPPT 100|30 Solar Charge Controller
  • Two (2) Rich Solar 200W 12V Solar Panels
  • Victron Orion XS 12-12|50 Non-Isolated DC-DC Charger

EXPEDITION TRUCK ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:

Installation tutorial shown in the video below shows the same concepts in a different system. Some products may vary.



Additional information

Battery Bank Voltage

12V

Application

Expedition Truck

Shore Power Amperage

30A
