EXPLORE XX 10KVA (DUAL 5KVA) 48V OFF-GRID CABIN WIRING KIT
This Off-Grid Cabin electrical system wiring kit features two Victron Quattro 48/5000/70-100/100 120V Inverter/Chargers for an off-grid cabin. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.
Click the arrow
next to each kit name for specifics on what is included in the kit.
IMPORTANT NOTE: This kit includes the DC side of the system wiring. All AC wiring as shown in the wiring diagram can be purchased at your local home improvement store.
START WITH YOUR BASE KIT #1 BELOW:
Description
EXPLORE XX DUAL 5KVA 48V OFF-GRID CABIN WIRING KIT
This Off-Grid Cabin electrical system wiring kit features two Victron Quattro 48/5000/70-100/100 120V Inverter/Chargers for an off-grid cabin or tiny house, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components (EXCLUDING BATTERIES), wiring, fusing, and connectors for:
- Two (2) Victron Quattro 48/5000 70-100/100 120V Inverter/Chargers
- Victron Lynx Power In for 4 x 100Ah 48V Batteries in a 48V Battery Bank
- Two (2) Victron Lynx Distributors
- Victron Lynx Shunt
- Cerbo GX Monitoring
- Victron Solar Charge Controller Options
IMPORTANT NOTE: This kit includes the DC side of the system wiring. All AC wiring as shown in the wiring diagram can be purchased at your local home improvement store.
BATTERY OPTIONS FOR EXPLORE XX DUAL 5KVA 48V OFF-GRID CABIN WIRING KIT
This system is designed for 4 x 100Ah 48V Rich Solar Alpha 5 Server Rack Batteries. For additional batteries over 4, you will need an additional Lynx Power In.
Orders of 4 or more Alpha 5 Server Rack Batteries will include the Server Rack at no additional cost.
OFF-GRID CABIN ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:
Installation tutorial shown in the video below shows the complete installation of this system. Some products may vary.
Additional information
| Battery Bank Voltage | 48V |
|---|---|
| Application | Off-Grid Cabin |
| Shore Power Amperage | 30A |
