EXPLORE LIGHT 30A TOW BEHIND CAMPER WIRING KIT

This 30A Tow Behind Camper Electrical System Wiring Kit is based around a Victron 2000VA Inverter. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.

Click the arrow next to each kit name for specifics on what is included in the kit.

*Batteries are NOT included in this kit, but after your purchase, you will receive a discount code for Battle Born Batteries. Options for batteries are listed in the product description below.

START WITH YOUR BASE KIT #1 BELOW:

SKU: bundle-explorelight-30atowbehindcamper Categories: ,

Description

EXPLORE LIGHT 30A TOW BEHIND CAMPER WIRING KIT

This is the DIY 30A camper electrical system wiring upgrade kit featuring a Victron Multiplus 2000VA Inverter/Charger, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components (EXCLUDING BATTERIES), wiring, fusing, and connectors for:

  • Victron MultiPlus 12/2000 80-50 120V Inverter/Charger
  • 30A OEM RV Inverter/Charger Retrofit Splice Box
  • Wiring Kit for 4 Batteries
  • Victron Lynx Distributor
  • Victron BMV-712 Monitoring
  • Victron VE.Bus Smart Dongle
  • Victron SmartSolar MPPT 100|30 Solar Charge Controller
  • Two (2) Rich Solar 200W 12V Solar Panels
  • Victron Orion TR-Smart 12-12|30 Isolated DC-DC Charger

BATTERY OPTIONS FOR EXPLORE LIGHT 30A TOW BEHIND CAMPER WIRING KIT

The following battery options are suitable for this system. The required minimum quantity is listed below:

COMPONENTQUANTITYLINK TO BUY
Suitable Battery Options (minimum 200Ah required):
Battle Born 100Ah 12V LiFePO4 Deep Cycle Battery2+CLICK TO BUY
Battle Born 100Ah GC2 12V LiFePO4 Deep Cycle Battery2+CLICK TO BUY
Battle Born 270Ah 12V LiFePO4 Deep Cycle GC3 Battery1+CLICK TO BUY
Battle Born 270Ah 12V LiFePO4 Deep Cycle Heated GC3 Battery1+CLICK TO BUY

30A TOW BEHIND CAMPER ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:

Installation tutorial shown in the video below shows the same concepts in a different system. Some products may vary. See our Installation and Product Tutorials for additional installation instructions.



Additional information

Battery Bank Voltage

12V

Application

Tow-Behind Camper

Shore Power Amperage

30A
