EXPLORE 12V 50A EXPEDITION TRUCK WIRING KIT

Description

EXPLORE 12V 50A EXPEDITION TRUCK WIRING KIT

This customizable expedition truck electrical system kit features a Victron MultiPlus-II 12/3000 120-50 2x120V Inverter/Charger and includes the batteries, components, wiring kits, fusing, and connectors needed to build the system shown in the diagram.

The default selections include the components, wiring, fusing, and connectors for:

• Victron MultiPlus-II 12/3000 120-50 2x120V Inverter/Charger
• 2 SOK 12V 314Ah LiFePO4 Batteries
• Victron Lynx Distributor
• Victron Cerbo GX MK2, GX Touch 70, and SmartShunt 500A Monitoring
• 120V AC Distribution Panel
• 12V DC Fuse Panel
• 50A Shore Power Inlet, Cord, and Adapters
• 1,500W Roof-Mounted Solar Array with 6 Rich Solar 250W Solar Panels and a Victron SmartSolar MPPT 150|100
• Redarc BCDC Alpha100 R Alternator Charging
• 12V and 120V Branch Circuits
• EXPLORE 12V 50A Van/Expedition Truck/Skoolie Wiring Diagram

The default selections are shown in the bundle builder but can be customized based on the needs of your system. Wiring kits can be selected as Un-Crimped (DIY) or upgraded to Pre-Crimped (PRO) wiring, professionally cut, crimped, heat-shrunk, and labeled by our in-house team.

Not sure what you need? Reach out to our support team at https://shop.explorist.life/support, and we’ll get you pointed in the right direction.

Want us to install it for you? Learn more at https://shop.explorist.life/installations/.

EXPLORE 12V 50A EXPEDITION TRUCK WIRING KIT FULL TUTORIAL:

Installation tutorial shown in the video below shows the complete installation of this system. Some products may vary.
