1200W Solar Charging Wiring Kit (6x 200W | 12V Battery Bank)

From: $0.00

Victron SmartSolar MPPT 150|85

The Victron SmartSolar MPPT 150|85 can regulate a solar array with an open circuit voltage of up to 150V down to charge a 12V, 24V, 36V, or 48V battery bank at a max rate of 85A, giving great flexibility when designing a solar array.

$453.05

In stock |Please allow 1-3 business days for processing.

Victron SmartSolar MPPT 150|85 Wiring Kit

$94.99

Solar Array Wiring Kit (Single/Dual/Ground Deploy Array Options)

2-to-1 PV Branch Connector

$12.99

In stock |Please allow 1-3 business days for processing.

PV Connector

$2.49 each

In stock |Please allow 1-3 business days for processing.

10 AWG Solar Wire

Red and Black Solar Wire - Sold in 10ft increments

15A PV Fuse

$13.99 each

In stock |Please allow 1-3 business days for processing.

Rich Solar Mega 200 Watt 12 Volt Solar Panel

$219.99 each

Rich Solar Mounting Hardware Z Brackets

This Rich Solar Mounting Hardware Z Brackets are a great solution for mounting rigid solar panels to the roof of your camper.

$12.99 each

Please allow 1-3 business days for processing.

SKU: bundle-solarcharging-6x200-12 Categories: , ,

Description

This solar charging wiring kit includes everything you need to be able to connect 6x 200w solar panels in series-parallel to your Victron Lynx Distributor that is charging your 12V battery bank.

Wiring Diagram:

Here is the wiring diagram for this solar charging kit:

Additional information

Battery Bank Voltage

12V

Solar Panel Wattage

200W

Solar Panel Style

Rigid Panel

Victron SmartSolar MPPT 150|85

Weight 12 lbs
Dimensions 13 × 11.5 × 6.5 in
Max Input Voltage

150V

Max Amperage Output

85A

Battery Bank Voltage

12V, 24V, 36V, 48V

Max Wire Size

2 AWG

Victron SmartSolar MPPT 150|85 Wiring Kit

Weight 4 lbs
Dimensions 10 × 10 × 2 in

Solar Array Wiring Kit (Single/Dual/Ground Deploy Array Options)

Weight 2.5 lbs
Dimensions 10 × 10 × 4 in
Choose Your Array Type:

Single Roof Array, Dual Roof Array, Roof and Ground Deploy Arrays, Single Roof Array for OEM Solar Ready, Add-On Ground Deploy Array, Add-On 2nd Roof Array

2-to-1 PV Branch Connector

Weight .3 lbs
Dimensions 3 × 5 × 1 in

PV Connector

Weight .2 lbs
Dimensions 4 × 1 × 1 in

10 AWG Solar Wire

Weight .2 lbs
Dimensions 10 × 10 × .1 in
Feet

10 ft., 20 ft., 30 ft., 40 ft., 50 ft., 60 ft., 70 ft., 80 ft., 90 ft., 100 ft.

15A PV Fuse

Weight .2 lbs
Dimensions 4 × 1 × 1 in

Rich Solar Mega 200 Watt 12 Volt Solar Panel

Weight 26.5 lbs
Dimensions 58.7 × 26.8 × 1.4 in
Solar Panel Wattage

200W

Rich Solar Mounting Hardware Z Brackets

Weight .5 lbs
Dimensions 4 × 6 × 2 in
