EXPLORE XX 6KVA 48V 50A TOW BEHIND CAMPER WIRING KIT

Description

EXPLORE XX 6KVA 48V 50A TOW BEHIND CAMPER WIRING KIT

This customizable tow behind camper electrical system kit features two Victron MultiPlus-II 48/3000/35-50 120V Inverter/Chargers and includes the batteries, components, wiring kits, fusing, and connectors needed to build the system shown in the diagram.

The default selections include the components, wiring, fusing, and connectors for:

• Two Victron MultiPlus-II 48/3000/35-50 120V Inverter/Chargers
• Four Rich Solar ALPHA 5 PRO 48V 100Ah LiFePO4 Server Rack Batteries
• Victron Lynx Power In
• Victron Lynx Shunt VE.Can
• Two Victron Lynx Distributors
• Two Dual Inverter/Charger Splitter Boxes
• 50A OEM RV Inverter/Charger Retrofit Splice Box
• Victron Cerbo GX MK2 and GX Touch 70 Monitoring
• 2,000W Roof-Mounted Solar Array with Victron SmartSolar MPPT 250|60
• Sterling Power BB1248120 Alternator Charging with BBR Remote
• This kit is based around this EXPLORE XX 6kVA 48V 50A TOW BEHIND CAMPER WIRING DIAGRAM

The default selections are shown in the bundle builder but can be customized based on the needs of your system. Wiring kits can be selected as Un-Crimped (DIY) or upgraded to Pre-Crimped (PRO) wiring, professionally cut, crimped, heat-shrunk, and labeled by our in-house team.

Not sure what you need? Reach out to our support team at https://shop.explorist.life/support, and we’ll get you pointed in the right direction.

Want us to install it for you? Learn more at https://shop.explorist.life/installations/.

---

BATTERY OPTIONS FOR EXPLORE XX 6KVA 48V 50A TOW BEHIND CAMPER WIRING KIT

This system is designed for 4 x 100Ah 48V Rich Solar Alpha 5 Pro Server Rack Batteries. For additional batteries over 4, you will need an additional Lynx Power In.

---

EXPLORE XX 6KVA 48V 50A TOW BEHIND CAMPER WIRING KIT FULL TUTORIAL:

Installation tutorial shown in the video below shows the complete installation of this system. Some products may vary.
