EXPLORE XX 10KVA TOW BEHIND CAMPER 48V WIRING KIT
This 48V Tow Behind Camper electrical system wiring kit features two Victron Quattro 48/5000/70-100/100 120V Inverter/Chargers for a 50A OEM RV. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.
Click the arrow
next to each kit name for specifics on what is included in the kit.
START WITH YOUR BASE KIT #1 BELOW:
Description
EXPLORE XX 10KVA TOW BEHIND CAMPER 48V WIRING KIT
This 50A Tow Behind Camper electrical system wiring kit features two Victron Quattro 48/5000/70-100/100 120V Inverter/Chargers for a 50A OEM RV or motorhome, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components, wiring, fusing, and connectors for:
- Two (2) Victron Quattro 48/5000 70-100/100 120V Inverter/Chargers
- Four (4) 100Ah 48V Rich Solar Lithium Rack Style Batteries
- Victron Lynx Power In for 4 x 100Ah 48V Batteries in a 48V Battery Bank
- Two (2) Victron Lynx Distributors
- Victron Lynx Shunt
- Cerbo GX Monitoring
- Victron Solar Charge Controller Options
- Sterling Power BB1248120 Alternator Charging
BATTERY OPTIONS FOR EXPLORE XX DUAL 5KVA 48V TOW BEHIND CAMPER WIRING KIT
This system is designed for 4 x 100Ah 48V Rich Solar Alpha 5 Pro Server Rack Batteries. For additional batteries over 4, you will need an additional Lynx Power In.
48V TOW BEHIND CAMPER ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:
Installation tutorial shown in the video below shows the complete installation of this system. Some products may vary.
Additional information
| Battery Bank Voltage | 48V |
|---|---|
| Application | Tow-Behind Camper |
| Shore Power Amperage | 50A |
