EXPLORE 48V 30A MOTORHOME WIRING KIT

Description

EXPLORE 48V 30A MOTORHOME WIRING KIT

This customizable motorhome electrical system kit features a Victron MultiPlus-II 48/3000/35-50 120V Inverter/Charger and includes the batteries, components, wiring kits, fusing, and connectors needed to build the system shown in the diagram.

The default selections include the components, wiring, fusing, and connectors for:

• Victron MultiPlus-II 48/3000/35-50 120V Inverter/Charger
• 2 Rich Solar ALPHA 5 PRO 48V 100Ah LiFePO4 Lithium Server Rack Batteries
• Victron Lynx Power In, Lynx Shunt VE.Can, and Lynx Distributor
• Victron Cerbo GX MK2, GX Touch 70, and Lynx Shunt Monitoring
• 30A OEM RV Inverter/Charger Retrofit Splice Box and OEM RV AC Wiring
• 2,000W Roof-Mounted Solar Array with Victron SmartSolar MPPT 250|60
• Sterling Power BB1248120 12V/24V to 48V Battery-to-Battery Charger with BBR Remote
• EXPLORE 48V 30A MOTORHOME WIRING DIAGRAM

The default selections are shown in the bundle builder but can be customized based on the needs of your system. Wiring kits can be selected as Un-Crimped (DIY) or upgraded to Pre-Crimped (PRO) wiring, professionally cut, crimped, heat-shrunk, and labeled by our in-house team.

Not sure what you need? Reach out to our support team at https://shop.explorist.life/support, and we’ll get you pointed in the right direction.

Want us to install it for you? Learn more at https://shop.explorist.life/installations/.

BATTERY OPTIONS FOR EXPLORE 48V 30A MOTORHOME WIRING KIT

This system is designed for up to 4 x 100Ah 48V Rich Solar Alpha 5 Pro Server Rack Batteries. For additional batteries over 4, you will need an additional Lynx Power In.

---

48V MOTORHOME ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:

Installation tutorial shown in the video below shows the complete installation of this system. Some products may vary.
