800W Solar Charging Wiring Kit (4x 200W | 12V Battery Bank)

From: $677.68

Victron SmartSolar MPPT 150|60

$539.75

In stock  | Please allow 1-3 business days for processing.

Victron SmartSolar MPPT 150|60 Wiring Kit

$89.99

In stock  | Please allow 1-3 business days for processing.

Solar Array Wiring Kit (Single/Dual/Ground Deploy Array Options)

PV Connectors × 4

$2.49 each

In stock  | Please allow 1-3 business days for processing.

10 AWG Solar Wire

Red and Black Solar Wire - Sold in 10ft increments

Rich Solar 200W 12V Solar Panel × 4

Please allow 1-3 business days for processing.

This solar charging wiring kit includes everything you need to be able to connect 4x 200w solar panels in series to your Victron Lynx Distributor that is charging your 12V battery bank.

Wiring Diagram:

Here is the wiring diagram for this solar charging kit:

Battery Bank Voltage

12V

Solar Panel Wattage

200W

Victron SmartSolar MPPT 150|60

Weight 7.5 lbs
Dimensions 11 × 10 × 5.5 in
Max Input Voltage

150V

Max Amperage Output

60A

Battery Bank Voltage

12V, 24V, 48V

Max Wire Size

2 AWG

Victron SmartSolar MPPT 150|60 Wiring Kit

Weight 4 lbs
Dimensions 10 × 10 × 2 in
Battery Bank Voltage

12V, 24V, 36V, 48V

Max Amperage Output

60A

Max Input Voltage

150V

Max Wire Size

2 AWG

Solar Array Wiring Kit (Single/Dual/Ground Deploy Array Options)

Weight 2.5 lbs
Dimensions 10 × 10 × 4 in
Choose Your Array Type:

Single Roof Array, Dual Roof Array, Roof and Ground Deploy Arrays, Add-On Ground Deploy Array, Add-On 2nd Roof Array

PV Connectors

Weight .2 lbs
Dimensions 4 × 1 × 1 in

10 AWG Solar Wire

Weight .2 lbs
Dimensions 10 × 10 × .1 in
Feet

10 ft., 20 ft., 30 ft., 40 ft., 50 ft., 60 ft., 70 ft., 80 ft., 90 ft., 100 ft.

Rich Solar 200W 12V Solar Panel

Weight 26.5 lbs
Dimensions 58.7 × 26.8 × 1.4 in
Solar Panel Wattage

200W

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.
