EXPLORE EXPEDITION TRUCK WIRING KIT
This Expedition Truck Electrical System Wiring Kit is based around a Victron 3000VA Inverter. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.
Click the arrow
next to each kit name for specifics on what is included in the kit.
START WITH YOUR BASE KIT #1 BELOW:
Description
EXPLORE EXPEDITION TRUCK WIRING KIT
This is the DIY expedition truck electrical system wiring kit featuring a Victron Multiplus 3000VA Inverter/Charger, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components (EXCLUDING BATTERIES), wiring, fusing, and connectors for:
- Victron MultiPlus 12/3000 120-50 120V Inverter/Charger
- Wiring Kit for 6 Batteries
- Victron Lynx Distributor
- Victron BMV-712 Monitoring
- Victron VE.Bus Smart Dongle
- Progressive Dynamics 120V AC Distribution Panel
- Progressive Dynamics 12V DC Fuse Panel
- 30A Shore Power Inlet (Black)
- Victron SmartSolar MPPT 150|85 Solar Charge Controller
- Four (4) Rich Solar 200W 12V Solar Panels
- Victron Orion XS 12-12|50 Non-Isolated DC-DC Charger
EXPEDITION TRUCK ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:
Installation tutorial shown in the video below shows the complete installation of this system. Some products may vary.
Additional information
| Battery Bank Voltage | 12V |
|---|---|
| Application | Expedition Truck |
| Shore Power Amperage | 30A |
