12V Camper Branch Circuit Guidebook

(1 customer review)

$9.99

Please allow 1-3 business days for processing.

SKU: virtual-guidebook-12vbranch Categories: , , Tag:

Description

This is a 7-page guidebook for installing 12V accessories that will show you common ways to wire the 12V accessories around your camper like lights, fans, USB outlets, and such.  This guidebook includes the wiring examples as well as recommended wire and fuse size recommendations that are specific to the items being powered.  The following circuits are shown:

  • 12V Lights – Switched with functional LED switch indicator
  • 12V Lights – Switched with led switch indicator disabled
  • Alternate wiring for 12V lights
  • 12V Lights – Switch w/ dimmer
  • 12V lights – 3 way switch (Switches in 2 separate locations)
  • 12V lights – 3 way switch with dimmer (Switches in 2 locations, dimmable from 1 location)
  • 12V lights – powered from a switch panel
  • Single Maxxair Fan
  • Dual Maxxair Fans
  • 12V Outlets
  • Combo 12V USB Outlet / 12V Outlet
  • USB Outlets
  • Water Pump
  • 12V Refrigerator

You can learn more about and source all of the little bits and pieces found in the guidebook here: https://www.explorist.life/12v-branch-circuits-parts/

Note: This is a high-resolution PDF eBook.  Although it is indeed able to be printed, some of the smallest details on the page may be too small to see when printed (like the ‘spade connector’ label on the spade connectors), but are completely visible when viewed digitally.

1 review for 12V Camper Branch Circuit Guidebook

  1. Peter Coleman (verified owner) –

    Hi Nate & Steph,
    I bought a couple of your wiring diagrams last week as a bit of inspiration in to the development of a system for my own van, Including the 12V branch circuit one
    I have to compliment you on the quality of the diagrams, which can only truly be appreciated when you have the ability to zoom right in to get ALL the detail, even down to the heat shrink on each terminal. Also the pre-calculated wire gauge/length calculations make it really easy on this pack.
    Being in Australia, I do have to change the inverter for a 240V Multiplus II, but that’s the easy part. I only wish that it was a simple as it would be ordering kits off of you guys over here. In my area I am finding that not many of our auto elec’s are familiar with Victron, most are promoting Redarc or Enerdrive, both good systems, but they just don’t seem to have the edge compared to Victron IMHO.
    Thanks for your work, it’s really appreciated.
    If you’re ever after a point of contact in Australia, feel free to reach out.
