EXPLORE MINI OVERLAND VEHICLE ELECTRICAL SYSTEM WIRING KIT
The EXPLORE MINI Overland Vehicle Wiring Kit is a customizable 800VA overland vehicle electrical system that includes everything you need to power your camper. This kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.
Click the arrow
next to each kit name for specifics on what is included in the kit.
START WITH YOUR BASE KIT #1 BELOW:
Description
EXPLORE MINI OVERLAND VEHICLE ELECTRICAL SYSTEM WIRING KIT
This is the DIY overland vehicle electrical system wiring kit featuring a Victron Phoenix 800VA Inverter, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components, wiring, fusing, and connectors for:
- 12V Victron Phoenix 800VA Inverter
- Optional Battery (System Requires 100Ah Minimum Battery Bank Capacity)
- Up to 400W Solar on Single Charge Controller
- Multiple Configurations Available
- Victron Orion XS 12|12-50A Alternator Charging
- 30A/15A Victron Blue Smart Charger
- And EVERYTHING needed to install these components
See below for the full list of everything that is included.
Camper electrical systems are hard. We sweat the small stuff so you don’t have to.
What’s Included in the EXPLORE MINI?
Default Selections included as described below. Alternative options can be selected in the design stage.
Components Included
| COMPONENT | QTY |
| Phoenix Inverter 12/800 120V VE.Direct NEMA GFCI | 1 |
| Blue Sea Systems 7748 SafetyHub 150 Fuse Block | 1 |
| Blue Smart IP22 Charger 12/30(1) 120V NEMA 1-15P | 1 |
| Victron Smart Shunt 500A IP65 | 1 |
| Victron SmartSolar MPPT 100|30 | 1 |
| Victron Orion XS 12V-12V | 50A Non-Isolated DC-DC Charger | 1 |
Wiring Included
| COMPONENT | QTY |
| 6 AWG Primary Wire – Black | Spool 50′ |
| 6 AWG Primary Wire – Red | Spool 50′ |
| 10 AWG Solar Wire – Black | 20ft |
| 10 AWG Solar Wire – Red | 20ft |
Fuses/Breakers Included
| COMPONENT | QTY |
| 150 Amp Surface Mount Circuit Breaker | 1 |
| 60 Amp Surface Mount Circuit Breaker | 1 |
| 60A MIDI Fuse | 3 |
| 100A MIDI Fuse | 1 |
| 2 Pole Solar Isolator Breaker | 1 |
Connectors/Lugs/Ferrules Included
| COMPONENT | QTY |
| PV Connectors | 2 |
| Junction Block Small Base 5/16″ | 1 |
| 10 AWG Ferrule | 4 |
| 10 AWG Insulated Ferrule | 2 |
| 6 AWG Insulated Ferrule | 8 |
| 6 AWG x 1/4″ Ring Terminal | 5 |
| 6 AWG x 3/8″ Ring Terminal | 2 |
| 6 AWG x 5/16″ Ring Terminal | 19 |
Mounting Hardware Included
| COMPONENT | QTY |
| 2 Pole Solar Isolator Hardware | 1 pk |
| #14 Charge Controller Hardware | 1 pk |
| BlueSmart Charger Mounting Hardware | 1 pk |
| Orion XS Mounting Hardware | 1 pk |
| Phoenix Mounting Hardware | 1 pk |
| Victron BMV-712 Shunt/SmartShunt Mounting Screws | 1 pk |
EXPLORE MINI OVERLAND VEHICLE ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:
Additional information
| Battery Bank Voltage | 12V |
|---|---|
| Application | Overland Vehicle |
| Shore Power Amperage | 15A |
