EXPLORE 24V VAN WIRING KIT
This Camper Van Electrical System Wiring Kit is based around a Victron 3000VAÂ 24V Inverter. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.
Click the arrow
next to each kit name for specifics on what is included in the kit.
START WITH YOUR BASE KIT #1 BELOW:
Description
EXPLORE 24V VAN WIRING KIT
This is the DIY camper van electrical system wiring kit featuring a Victron 24V Multiplus-II 24/3000 Inverter/Charger, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections (which are customizable) include the components, wiring, fusing, and connectors for:
- Victron Multiplus-II 24/3000 70-50 120V Inverter/Charger
- Wiring Kit for 2 Batteries (wired into a 24V battery bank)
- Victron Lynx Distributor
- Victron Orion 24/12-70A DC-DC Converter
- Victron Cerbo GX Monitoring
- Progressive Dynamics 120V AC Distribution Panel
- Progressive Dynamics 12V DC Fuse Panel
- 30A Shore Power Inlet (Black)
- Victron SmartSolar MPPT 150|35 Solar Charge Controller
- Four (4) Rich Solar 250W 12V Solar Panels
- Victron Orion TR-Smart 12-24|15 Isolated DC-DC Charger
CAMPER VAN ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:
Installation tutorial shown in the video below shows the same concepts in a different system. Some products may vary. See our Installation and Product Tutorials for additional installation instructions.
Additional information
| Battery Bank Voltage | 24V |
|---|---|
| Application | Camper Van |
| Shore Power Amperage | 30A |
