EXPLORE 30A TOW BEHIND CAMPER 24V WIRING KIT
This 30A Tow behind camper 24V Electrical System Wiring Kit is based around a Victron 24V 3000VA Inverter. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.
Click the arrow
next to each kit name for specifics on what is included in the kit.
START WITH YOUR BASE KIT #1 BELOW:
Description
EXPLORE 30A TOW BEHIND CAMPER 24V WIRING KIT
This is the DIY 30A Tow behind camper electrical system wiring upgrade kit featuring a Victron Multiplus 24V 3000VA 120 Inverter/Charger, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components (EXCLUDING BATTERIES), wiring, fusing, and connectors for:
- Victron MultiPlus 24/3000 70-50 120V Inverter/Charger
- 30A OEM RV Inverter/Charger Retrofit Splice Box
- Wiring Kit for 4 12V Batteries in a 24V Battery Bank
- Victron Lynx Distributor
- Victron BMV-712 Monitoring
- Victron VE.Bus Smart Dongle
- Victron SmartSolar MPPT 100|35 Solar Charge Controller
- Four (4) Rich Solar 250W Solar Panels
- Victron Orion TR-Smart 12-24|15 Isolated DC-DC Charger
30A TOW BEHIND CAMPER 24V ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:
Installation tutorial shown in the video below shows the same concepts in a different system. Some products may vary. See our Installation and Product Tutorials for additional installation instructions.
Additional information
| Battery Bank Voltage | 24V |
|---|---|
| Application | Tow-Behind Camper |
| Shore Power Amperage | 30A |
