EXPLORE XX EXPEDITION TRUCK DUAL INVERTER WIRING KIT
This 50A Expedition Truck Electrical System Wiring Kit is based around Dual Victron Multiplus-II 24/3000 70-50 2x120V Inverter/Chargers. The kit can be customized to your needs by following the steps below. The default selections are the selections as shown in the wiring diagram, but you can change quantities or remove items as needed.
Click the arrow
next to each kit name for specifics on what is included in the kit.
START WITH YOUR BASE KIT #1 BELOW:
Description
EXPLORE XX EXPEDITION TRUCK DUAL INVERTER WIRING KIT
This 50A expedition truck electrical system wiring kit features two Victron Multiplus-II 24V 3000VA 2x120V Inverter/Chargers for an expedition truck with 50A shore power, as shown in this diagram. The default selections are as shown in the diagram, but can be customized based on your needs. The default selections include the components (EXCLUDING BATTERIES), wiring, fusing, and connectors for:
- Two (2) Victron MultiPlus-II 24/3000 70-50 2x120V Inverter/Chargers
- Wiring Kit for 4 12V Batteries in a 24V Battery Bank
- Two (2) Victron Lynx Distributors
- Victron BMV-712 Monitoring
- Victron VE.Bus Smart Dongle
- Two (2) EXPLORIST.life Dual Inverter Splitter Boxes
- Progressive Dynamics 120V AC Distribution Panel
- Progressive Dynamics 12V DC Fuse Panel
- Victron Orion 24|12-70 DC-DC Converter
- 50A Shore Power Inlet (Black)
- Victron SmartSolar MPPT 150|60 Solar Charge Controller
- Eight (8) Rich Solar 200W 12V Solar Panels
- Two (2) Victron Orion TR-Smart 12-24|15 Isolated DC-DC Chargers
EXPEDITION TRUCK ELECTRICAL SYSTEM WIRING KIT FULL TUTORIAL:
Installation tutorial shown in the video below shows the complete installation of this system. Some products may vary.
Additional information
| Battery Bank Voltage | 24V |
|---|---|
| Application | Expedition Truck |
| Shore Power Amperage | 50A |
