2000w INVERTER | 200-400Ah Lithium | 200W-520W Solar – High Res Wiring Diagram

Description

This is a High-Resolution PDF of the wiring diagram found here: https://www.explorist.life/2000w-520w-60a-budget-friendly-camper-wiring-diagram/

If you’re looking for a wiring diagram that is more zoom-in / print-off friendly than what is in the above link, this is what you are looking for.

TIPS FOR DOWNLOADING:

Although these PDF’s will usually open in your web browser, if you have issues, try opening the PDF with the free Adobe Reader. Safari on Mac is particularly prone to not working well with these PDF’s, so that’s you best option there. If you still can’t open the file, feel free to send a support ticket with your order number and the title of the diagram you are having issues with at shop.explorist.life/support and we will get you squared away.

NOT FOR COMMERCIAL USE

These diagrams are copyright protected and are not to be shared with anyone anywhere. It may not seem like much, but the $10 you pay for this diagram truly does support all of the free content and tutorials that we put out. If you are a commercial builder or upfitter, please email us for permission if you would like to install these systems in your commercial builds.
